CBB61 AC motor run capacitor TPCA03

CBB61 AC motor run capacitor


    CBB61 type capacitor gengrally use the quadrate anti-flaming plastic shell,epoxy resin packing .The type is of little shape and light weight,little wastage,high insulation resistance,excellent natural repair,good stability,suitable for alternating current circuit.

    This type capacitor is suitbale used in the frequency of 50-60Hz,voltage from 250v-500v single shase AC motors,fan,water pump etc.For starting and running .


1.Detail List(Parts)



CBB61
ModelSize
CBB61 With pin1UF14*24*37
1.5UF14*28*37
2UF14*28*37
2.5UF14*28*37
3UF14*28*47
3.5UF18*28*47
4UF18*28*47
4.5UF18*34*47
5UF18*34*47
6UF22*37*47
7UF22*37*47
8UF26*37*47
10UF23*37*58
12UF28*40*58
15UF28*40*58
16UF30*45*60
CBB61 with small box10UF18*32*57
12UF21*35*57
15UF21*35*57
15UF23*37*58
16UF23*37*58
generator 350V16UF21*35*57
20UF28*40*58
24UF30*45*60



WELCOME TO INQUIRY ! IF YOU NEED MORE INFROMATION, WELCOME TO VISIT OUR CAPACITOR WEBSITE: www.tprp.cn.
